UBIQUITI U7 Outdoor AP WiFi7 2x2 2.4/5GHz 2.5GbE Oudoor/Pole IPX6
เพิ่มเมื่อ: 2025-05-28 14:39:32.0
แก้ไขล่าสุด: 2025-05-28 14:40:18.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comACCESS POINT (แอคเซสพอยต์) UBIQUITI U7 Outdoor Access Point WiFi7 2x2 2.4/5GHz 2.5GbE Oudoor/Pole IPX6 (Not included power adapter) (รับประกัน 1ปี)
UBIQUITI U7 Outdoor
ACCESS POINT (แอคเซสพอยต์) UBIQUITI U7 Outdoor Access Point WiFi7 2x2 2.4/5GHz 2.5GbE Oudoor/Pole IPX6 (Not included power adapter)
WiFi Standard : WiFi 7
Spatial Streams : 4
Coverage Area : 465 m² (5,000 ft²)
Max. Client Count : 250+
Uplink : 2.5 GbE
Mounting :
Wall, Pole
(Mounts Included)
Weatherproofing : IPX6
Power Method : PoE+
MIMO :
5 GHz
2 x 2 (DL/UL MU-MIMO)
2.4 GHz
2 x 2 (DL/UL MU-MIMO)
Max. Data Rate :
5 GHz
4.3 Gbps (BW240)
2.4 GHz
688 Mbps (BW40)
Antenna Gain :
5 GHz
Directional internal: 12.5 dBi, 45° x 45°
External omni: 4 dBi, 360° x 30°
2.4 GHz
Directional internal: 8 dBi, 90° x 90°
External omni: 3 dBi, 360° x 30°
Max. TX Power :
5 GHz
26 dBm
2.4 GHz
23 dBm
Max. BSSIDs : 8 per Radio
Supported Data Rates :
802.11be (WiFi 7)
7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
802.11ax (WiFi 6)
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11n
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
Max. Power Consumption : 19W
Supported Voltage Range : 42.5—57V DC
Networking Interface : (1) 1/2.5 GbE RJ45 port
Weight : 1.2 kg (2.6 lb)
Wind Loading : 74.6 N at 200 km/h (16.8 lbf at 125 mph)
Pole Mount Diameter : 1–2.36" (25–60 mm)
Antennas :
(1) Directional internal antenna
(2) External omni antennas
(2) RP-SMA connectors for external antenna
Antenna beamwidth :
5 GHz
45°
2.4 GHz
90°
Management : Ethernet
Enclosure Material : UV-stabilized polycarbonate, aluminum alloy
Mount Material : Polycarbonate, SGCC steel
Channel Bandwidth : HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz)
Ambient Operating Temperature : -30 to 60° C (-22 to 140° F)
Ambient Operating Humidity : 5 to 95% noncondensing
Dimensions : 170 x 208 x 54.5 mm (6.7 x 8.2 x 2.1")
