| IP-COM G2228P-24-410W 26GE+2SFP Cloud Managed PoE Switch, power budget 370W
IP-COM G2228P-24-410W 26GE+2SFP Cloud Managed PoE Switch, power budget 370W
เพิ่มเมื่อ: 2025-06-02 12:58:23.0
แก้ไขล่าสุด: 2025-06-02 14:49:41.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comSWITCH (สวิตซ์) IP-COM G2228P-24-410W 26GE+2SFP Cloud Managed PoE Switch, power budget 370W (รับประกัน 3ปี)
IP-COM G2228P-24-410W
SWITCH (สวิตซ์) IP-COM G2228P-24-410W 26GE+2SFP Cloud Managed PoE Switch, power budget 370W
- Comply with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3af, IEEE802.3at,IEEE802.3x, IEEE802.3z, IEEE802.1p, IEEE802.1q standards
- 26 10/100/1000 Base-T Ethernet ports, 2 1000 Base-X SFP optical ports
- 8 K MAC address table and MAC address auto learning
- 24 PoE ports, single port output power 30W, Total power budget 370W
- 56Gbps non-blocking wire-speed forwarding
- Web platform remote management, mobile APP management
- 4M large cache
- Support QVLAN, DHCP Snooping, anti-loop, PoE timing, watchdog, etc
Interfaces :
(26)1GE RJ45 ports
(2)1GE SFP ports
PoE interface : (24) PoE(Pins 1, 2+; 3, 6-)
LED Indicator :
Power
Link/Act
PoE MAX
Switching capacity : 56Gbps
Forwarding rate : 41.7Mpps
Power method : 100-240V AC，50 / 60Hz
Power consumption : 410W
Total available PoE : 370W
Total available PoE : 30W
Lightning protection : Port: 6 KV Power：6 KV
Button : Funtion mode Button
Operating temperature : 0°C - 45℃
Storage temperature : -40°C - 70°C
Operating humidity : 10% - 90%,non-condensing
Storage humidity : 5% - 90%,non-condensing
Dimensions : 440mm*240mm*44mm
Mounting :
Rack mounting : support
Desktop mounting: support
Wall mounting: support
Enclosure material : Metal
PoE Management :
Support dynamic display of PoE consumption power and PoE remaining power
Support PoE ports on and off
Security features :
Support whitelist binding of MAC addresses, ports and VLAN
Support port isolation
VLAN :
Support VLAN transparent transmission
Support IEEE 802.1q VLAN
DHCP Server : Support DHCP Client
STP : Support loop guard on each port
Port mirroring : Support N: 1 port mirroring
QoS :
Support storm control on ports
Support ingress and egress rate limits on ports
Support port flow control
Cloud Management :
Support configuration delivery from ProFi Cloud management platform
Support ProFi App management
Support log reporting and fault detection
Support remote maintenance: reboot, backup, upgrade
Loading and upgrade :
Support HTTP upgrade
Support Configuration import and export
Management and maintenance :
Support web management and maintenance
Support Ping and Tracert tests
Support VCT
